DAIKIN FBA FDMA 12.5/14.0kW Single-Phase Ducted Outdoor

Daikin Premium FDMA Duct RZAV125FV1 outdoor unit.

BEST FOR:
1.  Designed for Modern Kiwi Homes.
2. Depth of Only 700mm for Precision Fit.
3. R32 Refrigerant for Enhanced Efficiency and Lower Global Warming Potential.

R22 RETROFIT CAPABILITY:

• Provides a cost effective and convenient upgrade from an existing R22 ducted system whilst retaining the field piping.*

NIGHT QUIET MODE:

• Reduces the outdoor noise levels during sleeping hours and automatically resumes normal operations in the morning.

BUILT-IN DRAIN PUMP:

• Built-in drain pump as standard.

COMPACT DESIGN:

• 140 and 160 Class is now housed in a compact indoor casing for easier installation.

ONLY FOR NZ MARKET:

• Specifically designed with New Zealand homes in mind.

R32 REFRIGERANT:

• R-32 has approximately a third of the global warming potential of R-410A and zero ozone depletion potential.

*Strict guidelines apply for R22 Retrofit Capability, please speak to your installer for further information.

Power Supply: 1 Phase, 200-240V, 50Hz.

Rated Capacity:

• Cool (kW): 12.5.
• Heat (kW): 15.0.

Power consumption:

• Cool (kW) / Heat (kW): 3.77 / 4.05.

Compressor:

• Type: Hermetically sealed swing type.
• Motor output (kW): 3.3.

Refrigerant charge (R-32): 3.7(Charged for 40m).

Sound pressure level :

• Cool (dBA) / Heat (dBA): 50 / 51.
• Night quiet mode (dBA): 46.

Dimensions (HxWxD): 870mmx1100mmx460mm.

Weight: 95kg.

Certified Operation Range:

• Cool (°CDB) / Heat (°CWB): -5 to 50 / -15 to 15.5.

Piping connections:

• Liquid (Flare) / Gas (Flare): Ø 9.5 / Ø 15.9.
• Indoor unit drain (mm): VP25 (I.D Ø25 x O.D Ø32).
• Outdoor unit drain (mm): Ø 26.0 (Hole).

Max. interunit piping length: 85 (Equivalent length 100).

Max. installation level difference: 30m.

Daikin premium FDMA Duct tech page 01
